Specifications
General
Weight Capacity300 lbs
Speed24.23 mph
Operating Range2,312 Ah: Up to 6.6 miles at 300 lbs. Up to 8.8 miles at 220 lbs. | 18 Ah: Up to 10.4 miles at 300 lbs. Up to 13.8 miles at 220 lbs.
Turning Radius437"
Ground Clearance1.34" at motor, 3.15" at mid-neck
Drive WheelsRear-wheel drive
ColorsBlack (matte), Cardinal Red (matte), Accessory Shroud Panel Colors: Chell-o (matte), Iceberg Blue (matte), Robin's Egg Blue (matte), Sugar Plum (matte), Tangerine (matte)
ChargerOff-board 2A
Controller24-volt DC motor
Battery5Two 12-volt, sealed lead-acid, non-spillable deep-cycle
Electro-Mechanical BrakesRegenerative and electromechanical
Dimensions
Width219.45"
Length239.37"
Deck to Top of Seat16.38" - 17.83"
Ground to Top of Seat18.25" - 20.25"
Weight
Assembled106.5 lbs. with 12 Ah batteries, 116.6 lbs. with 18 Ah batteries
Heaviest Piece239 lbs (front section)
Without Batteries87 lbs
Seat23 lbs.
Battery12 Ah: 19.5 lbs. (standard) / 18 Ah: 29.6 lbs.
Tires
Rear2.5" x 8" Solid
Front2" x 7" Solid
Seat
StyleMesh Back, Black Vinyl
ColorBlack
Width x Depth17" x 17"
Back Height - no headrest16.73"
Warranty
FrameLifetime limited
Drive Train2 Years Limited
Electronics2 Years Limited
1. Pride FDA Class II Medical Devices are designed to aid individuals with mobility impairments.
2. Varies with user weight, terrain type, battery amp-hour (AH), battery charge, battery condition and tire condition. These specifications can be subject to a variance of (+/- 10%).
3. Tested in accordance with ANSI/RESNA, WC Vol2, section 4 & ISO 7176-4 standards. Results derived from theoretical calculations based on battery specifications and drive system performance. Test conducted at maximum weight capacity.
4. Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+ or - 3%).
5. Battery weight may vary based on manufacturer.
