Raizer II Mobile Lifting Chair
Liftup

Raizer II Mobile Lifting Chair


Description


The battery-operated mobile lifting chair Raizer II helps a fallen person up to an almost standing position in a few minutes. The aid can be operated by only a single assistant, and it requires only limited physical effort from the operator aside from a helping hand.


A person who has fallen and cannot get up again is lifted up comfortably to a sitting or almost standing position in a way that supports the entire body throughout the process. This way of lifting shows consideration for the importance of being helped up in a dignified and safe way.


New ergonomic benefits

Raizer II is easily assembled under a fallen person, and the lifting process is swiftly initiated by a push of a button on the remote control or the control panel on the side of the seat. This means that the assistant does not have to carry out a lift and is exposed to no strain on the back or shoulders as you may experience with other appliances. A person working alone can easily manage the Raizer II and assist the fallen person.


The Raizer II can be used in home care, in institutions, for rescue services and other services requiring a lifting aid and transfer of persons with limited mobility.


Comfortable lift

All the materials have been carefully selected with special attention to stability and durability and considering both the helper and the fallen person.


Raizer II is fitted with safety belts that are to be attached to both backrests to make sure that the fallen person feels secure and comfortable during the lifting process. It is possible to attach additional safety belts on the backrests of Raizer II. Thus, the torso of the fallen person can be secured in several positions for increased comfort.


Exclusive and easy-to-clean design

Raizer II offers an exclusive and user-friendly design with intuitive sound and light indicators making it easy to quickly assemble the Raizer II at any location. The two backrests are alike, and the four identical legs can be swiftly fitted in any sequence thus making the Raizer II quick and easy to assemble under the fallen person.


All surfaces of Raizer II have been developed to be easy to clean as regards choice of materials and surface structure, and the surfaces of Raizer II may also be disinfected.


Mobile solution

The lifting chair is battery-powered and therefore there are no awkward power cords when operating. Raizer II is easily operated with a remote control which is kept on the side of the seat when not in use. Raizer II will emit a warning if the remote control is not returned to its place after use.


Easy to transport

When disassembled, Raizer II is carried in two bags to the location; backrests and legs are carried in a bag with ergonomic carrying straps for hand or back (long strap for shoulders or two straps as a backpack). The motor unit/seat is carried separately in a protective cover with a soft handle ergonomically designed to make sure that it is carried close to the body.


Alternatively, the Raizer II can be transported on a trolley (optional equipment) where both bags can be placed side by side. The Raizer II is disassembled after use and therefore is easy to transport and use anywhere and in any situation. We even offer a bike bracket kit (optional equipment) to mount the trolley behind a bicycle.


For use at:

Home

Hospitals

Institutions

Rescue services

Private users


Raizer II Accessories

Headrest

Carry case

Cover for seat

Remote control

Trolley

Triple wheels for trolley, 2 pcs.

Bicycle bracket, kit

Hygiene cover

Safety belt

Battery charger 15W, multi AC-plug

Charger cable, USB



Features


Mobile auxiliary aid to lift a fallen person

Comfortable and secure for the fallen person

Lifts up to 330 lbs

Easily assembled in just a few minutes

2 identical backrests and 4 identical legs make assembly easy

No physical strain for the helper

The fallen person and the helper can both feel safe

Improved cleanability: Can be disinfected

Battery indicator on control panel

Intuitive sound and light indicator for smooth assembly

Easy transportation in two bags

Alert on control panel for service inspection

Battery capacity: Approx. 80 lifts per charge

Seat dimensions: W: 27" / D: 10.1" / H: 7.5"



Specifications


General

Lifting Capacity

330 lbs

Lifting time

20-30 sec

Unit Weight

28.6 lbs

Operation

battery-operated

Seat Weight

18.7 lbs

Components Weight

9.9 lbs

Maximum Usage Limit

40 at max. load. Approx. 80 with an average load

Charging time

Up to 6 hours

Chargers

USB charger and 15W charger for standard power socket

Dimensions

Dimensions (WxDxH) - seat

27" / 10.1" / 7.5"
